Specifications

General Specifications

• Application: Vertical Riser, General Building Applications
• Cable Type: Tight-Buffered
• Flame Rating: Riser (OFNR)
• Cable Assembly Type: Two Fiber
• Fiber Category: Single-mode (OS2)

Design - Connector A

• Connector Type: LC duplex
• Ferrule Material: Ceramic
• Housing Material: Composite
• Housing Color: Blue
• Boot Color: Blue

Optical Specifications - Connector A

• Polish: UPC
• Reflectance, Typical: ≤ -58 dB
• Insertion Loss, Typical: 0.15 dB

Design - Connector B

• Connector Type: SC duplex
• Ferrule Material: Ceramic
• Housing Material: Composite
• Housing Color: Blue
• Boot Color: Blue

Optical Specifications - Connector B

• Polish: UPC
• Reflectance, Typical: ≤ -59 dB
• Insertion Loss, Typical: 0.15 dB

Cable Design

• Fiber Count: 2
• Outer Jacket Color: Yellow

Mechanical Characteristics Cable

• Nominal Outer Diameter: 4 mm

Furcation - Connector A

• Plug Type: Heat-shrink sleeve
• Plug Dimensions: 25.4 x 3.5 x 5.5 mm (1 x 0.14 x 0.22 in)
• Leg Diameter: 2 mm
• Leg Length in Inches - A: 10 in (+1.5 in/-0 in)
• Leg Length: 10 in (+1.5 in/-0 in) (254 mm (+38.1 mm/-0 mm))

Furcation - Connector B

• Plug Type: Heat-shrink sleeve
• Plug Dimensions: 25.4 x 3.5 x 5.5 mm (1 x 0.14 x 0.22 in)
• Leg Diameter: 2 mm
• Leg Length in Inches - B: 10 in (+1.5 in/-0 in)
• Leg Length 10 in (+1.5 in/-0 in) (254 mm (+38.1 mm/-0 mm))

Chemical Characteristics

• Free of hazardous substances according to RoHS 2002/95/ EG
