Specifications

General Specifications

• Flame rating: LSZH™/FRNC
• Cable assembly type: Two Fibre
• Fibre Category: 50 µm MM (OM3)

Temperature Range

• Operation: -20 °C to 60 °C
• Installation and assembly: -5 °C to 50 °C
• Storage: -25 °C to 70 °C

Design - Connector A

• Connector Type: LC Duplex
• Ferrule Material: Ceramic
• Polish: PC
• Housing material: Composite
• Housing Colour: black
• Boot type: Individual
• Boot colour: aqua / white
• Keyed (security): No

Mechanical Specifications - Connector A

• Durability: ≤ 0.2 dB 500 rematings, FOTP-21
• Tensile strength jacketed cable: 44 N

Optical Specifications - Connector A

• Insertion loss, typical: 0.35 dB
• Insertion loss, max:. 0.5 dB

Design - Connector B

• Connector Type: SC duplex
• Ferrule Material: Ceramic
• Polish: PC
• Housing material: Composite
• Housing Colour: black
• Boot type: Individual
• Boot colour: aqua / white
• Keyed (security): No

Mechanical Specifications - Connector B

• Durability: ≤ 0.2 dB 1000 rematings, FOTP-21
• Tensile strength jacketed cable: 44 N

Optical Specifications - Connector B

• Insertion loss, typical: 0.35 dB
• Insertion loss, max.: 0.5 dB

Cable design

• Fibre Count: 2
• Outer diameter: 1.8 mm x 3.7 mm
• Outer jacket colour: Turquoise
• Outer jacket material LSZH™/FRNC
• Minimum Bend Radius: 10 mm
• Crush resistance (reversible): 1000 N/10 cm
• Tensile strength: 300 N

Chemical Characteristics

• RoHS: Free of hazardous substances according to RoHS 2011/65/EU
